This visual guide collects the key images from the Wireless Energy Management System document. The system is intended to help installers and users understand monitoring hardware, communication devices and installation context for smart energy projects.
How to read the guide
Use the images as a quick reference for device appearance, wiring environment and on-site workflow. When preparing a project, pair this guide with the relevant inverter and ESS datasheets to confirm compatibility and installation requirements.
Installer note: verify communication range, enclosure location and power supply before finalising the installation layout.
